COM Application-Specific Solutions Baseboard I/O Functionality Extension Of Your R&D Team Program Development Flow

DIAMOND SYSTEMS IS AN EXTENSION OF YOUR R&D TEAM

Contact Us
Email us to discuss your application-specific COM Baseboard needs!

Working with us is like bringing an R&D partner on-board. Together we will engage in a consultative relationship to agree on a proposal, define specifications, build prototypes and begin production.

Diamond Systemsí development approach reduces your design risk by using state-of-the-art functional design blocks, allowing us the flexibility to produce a solution that meets your specifications in less time and at a lower development cost. Our design libraries and areas of expertise include:


Analog I/O Digital I/O
Serial I/O Ethernet
USB 2.0 GPS & Wireless
Relays & Opto-isolation FPGA & logic design
DC/DC power supply Counters & Timers
Operating system support Drivers and BIOS
System Integration Project Management


Whether your application requires a simple product variant or demands a full custom design, Diamond Systems will work with you to quickly and efficiently produce a solution to fit your embedded computing application.

We will work together in a phased project approach, beginning with a Definition Phase, followed by a Design Phase, Prototype Phase and then finally full production.


Definition Phase
Customer Requirements Document
Consultation with Diamond Systemsí Design Team
Diamond Systems Proposal
Joint Proposal Review
Final Proposal


Design Phase Activity Typical Timeframe
Develop Specification 1-2 weeks
Design schematics 2-3 weeks
PCB Design & Fabrication 3-4 weeks
Prototype Build 2 weeks
Design Verification 2-3 weeks


From Specification to Verified Prototype: 10 - 14 weeks!
